You have an incoming hot wire black going to one screw it does not matter if you use the brass or silver screw on the side of the 2 way switch and a black wire from the other screw on the 2 way switch going to the load light ceiling fan etc.

Light switch wiring diagram france. The hot and neutral terminals on each fixture are spliced with a pigtail to the circuit wires which then continue on to the next light. With a pair of 3 way switches either switch can make or break the connection that completes the circuit to the light. Easy to understand light switch wiring fully explained light switch wiring with diagrams and pictures with step by step instructions to guide you. The new one looks different to the old one so i do not know which holes to put the wire in.

Whether you have power coming in through the switch or from the lights these switch wiring diagrams will show you the light. Notice the black wire is the only wire that we are controlling through the 2 way switch. With alternate light switch wiring an nm cable supplies line voltage from the electrical panel to a light fixture outlet box. Wiring a three way light switch.

To clarify the main circuit breaker supplying the lights is double pole but the individual room light switch is single pole. Wiring of 3 way light switches is certainly more complicated than that of the more common single pole switch but you can figure it out if you follow our 3 way switch wiring diagram. There are just the 2 blue wires going through old switch. Another nm cable connects from the light fixture box to the switch box.

Just got back from france and read your reply to my last posting. This light switch wiring diagram page will help you to master one of the most basic do it yourself projects around your house. In the diagram below right a 2 wire nm cable that connects the light fixture to the switch carries 2 line wires one line and one switched line. Right i bought a new light switch as the one here was actually an old sock in the wall padding the gap to hold a broken but working live switch.

Multiple light wiring diagram. The source is at sw1 and 2 wire cable runs from there to the fixtures. Wiring a basic light switch with power coming into the switch and then out to the light is illustrated in this diagram. How to wire a light switch diagram 1 summary.

Also look out when try to test the light as some mains testers draw more than 30ma thats the trip signal for the main boards rcd.
