Ge shunt trip breaker. Magnetic replaceable trip units. Register using your email address to receive special offers and discount codes. Two shunt trips can be mounted in each power circuit breaker. Field installed breaker accessories each spectra rms circuit breaker accepts a full range of internal accessories including a wide array of shunt trip and undervoltage release devices as well as bell alarm and auxiliary switches.

A wide array of rating plugs is offered for each frame size see table 51. Shunt trip circuit breakers are used when an operator might wish to remotely trip a breaker because there is some problem in the circuit and the breaker hasnt opened normally. Assortment of ge shunt trip breaker wiring diagram. The power for the shunt trip does not come from within the breaker so it must be supplied from an external source.

Shunt trip breaker thqb32030st1 with 120v shunt bolt on circuit breaker with same day shipping from breaker outlet. General electric thqb single pole bolt on molded case circuit breaker with shunt trip miniature circuit breaker has a voltage rating of 120 vac 120240 vac and current rating of 20 amps. A shunt trip device is an optional accessory in a circuit breaker that mechanically trips the breaker when power is applied to the shunt trip terminals. A wiring diagram is a streamlined standard photographic representation of an electrical circuit.

A device designed to switch the power circuit breaker off remotely. When coupled with ge current limiting devices downstream and other instantaneous zone selective interlock i zsi capable devices upstream circuit breakers equipped with entelliguard family trip units including spectra with microentelliguard provide selective coordination without sacrificing arc flash risk. The devices are available as. Using the shunt trip circuit breaker as a remote controlled switch is not recommended since frequent switching of the circuit breaker will shorten its lifespan.
